1. Working bar stock diameter Ø3~Ø12 mm
2. Max. machining length:
guide bushless device: 45mm (package configuration),
rotary guide bushing device: 80mm (package configuration)/135mm (quick matching)
Electric guide bushing device: 170mm (optional)
Stationary guide bushing device: 210mm (option)
3. Max. Main spindle drilling diameter Ø7mm
4. Max. Main spindle tapping diameter M6
Introduction
The tool holder structure is further optimized and the rigidity is increased by more than 20%;
The spindle clamping force has been further improved to meet heavy cutting processing;
The structure on the side of the counter spindle is further strengthened to further
improve the tool life; the screw rod is thickened to 25mm;
The X2 and Z2 axis rapid traverse speeds are increased from 32 to 36m/s, making the efficiency higher.
characteristic
Main Specification
Model |
B0125-V | |
Machine capacity | Working bar stock diameter | Ø3~Ø12mm |
Max. machining length |
210mm-stationary guild; 80mm-rotary guide bushing; 135mm-electrical direct driving guild bush; 45mm-Guide bush less |
|
Main spindle hole diameter | Ø16mm | |
Max. Main spindle drilling diameter | Ø7mm | |
Max. Main spindle tapping diameter | M6 | |
Max. Back spindle drilling diameter | Ø8mm | |
Max. Back spindle tapping diameter | M8 | |
Max. Cross drilling diameter | Ø6mm(4-axis transverse power head/Rear tool post(option) | |
Max. Cross tapping diameter | M5(4-axis transverse power head/Rear tool post(option) | |
Machine | Main spindle speed | 200~12,000r/min |
Back spindle speed | 200~12,000r/min | |
Rotary guide bushing speed | 200~ 8,000r/min: carrier type rotary guide bushing; 200~10,000r/min: direct drive rotary guide bushing |
|
Tool spindle speed | 200 to 8,000r/min (Horizontal)/200 to8,000r/min(Rear drive) | |
Total tool storage capacity (Standard / Max. : Option) | 21 | |
Tool size | 12 mm x 12 mm x 85 mm | |
Rapid traverse rate | 36 m/min ( X 2,Z2),32 m/min(Y1,Z1),24m/min(X1) | |
Controlled axis ( linear axes ) | 5-axis | |
Motor speed conversion | Main spindle | 2.2/3.7kw |
Back spindle | 2.2/3.7kw | |
Cross drill |
1.0 KW 4-axis transverse power head), 0.75KW (/rear drive device (option) |
|
Coolant pump |
0.25KW |
|
Lubricating oil pump | 3 W | |
Power supply and others | Net weight | 1,950 kg |
Power source requirement | 6 kVA | |
Compressed air requirement | 0.4 MPa or above | |
Air discharge rate | 100 NL/min | |
Coolant tank capacity | 210L | |
Length x Width x Height | 2,015 x 1,175x 1,730mm |
