Swiss CNC Machine Manufacturers 6-axis Small Diameter Swiss Lathe SZ-126F

The newly designed lath body optimize with the help of finite element analysis(FEA),which is effective in absorbing vibration and reducing resonance while satisfying high rigidity and high precision machining.

Main/sub spindle rev speed:

2900/9790r/min,3870/11800r/min

Max feed length (once):

240mm

Main spindle max clamping dia:

Ø10mm

Inquiry

Write a Review

Introduction

6-axis Swiss type CNC lathe

● The newly designed lath body optimize with the help of finite element analysis(FEA),which is effective in absorbing vibration and reducing resonance while satisfying high rigidity and high precision machining.

● Because the Y-axis guide rail through the center of the ball screw is parallel to the cutting point,reducing the load of cutting resistance distance,so the Y axis direction and Z axis direction of the tool rest rigid increase ,prolong the life of the tool,improve the stability and accuracy of continuous processing.

206F刀具排列图-新

characteristic

Swiss CNC Machine Manufacturers 6-axis Small Diameter Swiss Lathe SZ-126F 4

Max tool installation 30pcs,rich cutting tools,suitable for the processing of complex parts.

Swiss CNC Machine Manufacturers 6-axis Small Diameter Swiss Lathe SZ-126F 5

Sub spindle side max install 14pic tools:4pcs turning tool,7pcs end face tools and 3pcs cross live tools,really realize multiple simultaneous processing,efficient production.

Swiss CNC Machine Manufacturers 6-axis Small Diameter Swiss Lathe SZ-126F 6

Use synchronous guide bush structure,realize high speed and high precision machining.

With guide bush and non guide bush mode ,flexible switching,to meet the needs of different processing technology.

Built in oil-cooled spindle has the advantages of small inertia,low noise ,fast response and easy positioning.

Main Specification

Model			SZ-126F
Cutting-tool layout sketch
NC device			FANUC Oi-TF Plus
Power source			200AVC
Lathe rated power			11Kw
Machining range		Machining range dia.	12mm
		Main spindle max clamping dia.	12mm
		Max feed length (once)	240mm
Main/sub spindle		Main spindle power	2.2/3.7Kw
		Sub spindle power	1.5/2.2Kw
		Main spindle max through hole dia.	13mm
		C axis resolution	0.001degree
		Main/sub spindle rev speed	2900/9790r/min 3870/11800r/min
		Sub spindle max clamping dia.	12mm
		Sub spindle max through hole dia.	13mm
		Main spindle max drilling depth	50mm
Main spindle max travel		With guide bush	240mm
Main spindle max travel		Non guide bush	360mm
Max tool installed qty.			30
Main spindle tool
①OD Turning tool		Qty.×Model	6X¨12mm
②Cross live tool		Qty.×Model	5XER16
		Drilling dia.	10mm
		Tapping/Threading die dia.	M6
		Live tool rev speed	Max 4000r/min
		Live tool power	1Kw
③End face fixed tool		Qty.×Model	5XER16
		Drilling dia.	10mm
		Tapping/Threading die dia.	M8
Sub spindle tool
⑥End face fixed		Qty.×Model	4×ER16
		Drilling dia.	Max 10mm
		Tapping/Threading die dia.	Max M8mm
Live tool	⑥End face live tool	Qty.×Model	3×ER16
		Drilling dia.	Max 10mm
		Tapping/Threading die dia.	Max M6
		Live tool rev speed	Max 5000r/min
		Live tool power	0.75Kw
	⑤Cross live tool	Qty.×Model	3×ER16
		Drilling dia.	Max 10mm
		Tapping/Threading die dia.	Max M6
④ OD Turning tool			4X¨12
Rapid feed speed			m/min(Z1/Z2/X2/Y1)24(X1/Y2)
Feed motor power			0.75Kw(Z1/Z2/X1/X2/Y1/Y2)
Cutting oil pump power			0.4Kw
Main/sub spindle cooling oil pump power			0.7Kw
Lubricating oil pump power			0.035Kw
Max collecting length of work pieces collect box			80mm
Main/sub spindle center to the bottom of lathe body			1018mm
Cutting oil tank volume			160L
Air pressure			≥0.5Mpa
Net weight			2800Kg
Dimensions(L×W×H)			2363X1402X1918mm

Note:Technical parameters are subject to change without prior notice.

Standard configuration

1. Taiwan SYNTEC 220TB control system Japan FANUC control system（option）

2. 10.4 inch Color LCD display

3. Main/sub spindle cooling system

4. Lubricating system

5. Rotatory driven guide bush

6. Main/sub spindle air blowing device

7. LED working light

8. Electric leakage protection

9. Transformer

10. 3-colour tower light

12. HIWIN/PMI screw/guide rail, Class 3

13. Cutting oil tank

14. Main/sub spindle collect 1pcs; guide bush 1 pcs

15. Tool cabinet

16. Chip conveyor

17. Manual book

Optional configuration

1. Automatic bar feeder

2. Chip conveyor

3. Oil mist collector

4. High pressure pump

5. Long work piece collector

7. External working light

8. Tap breakage detector

9. Cut-off tool breakage detector

10. Special shaped material clamping device

11. Thread whirling tool holder

12. Front eccentric tool holder
