Super cost-effective CNC precision automatic machine B0128W

1. Working bar stock diameter Ø3~Ø12 mm

2. Max. Main spindle drilling diameter Ø7mm

3. Max. Main spindle tapping diameter M6

4. Main spindle speed 200-12,000 r/min

Inquiry

Write a Review

Introduction

1. Front and rear tool tables independently driven B0 series.

2. Small investment, high returns: greatly shorten the processing cycle.

3. 3 systems are controlled simultaneously, and each tool station is controlled independently, realizing diversified processing on both the front and back sides at the same time.

4. 3 tool stations are equipped with Y axis.

5.Software thermal displacement compensation, realizing high-precision processing.

图片2 (12)

图片3 (3)

图片1 (7)

characteristic

Super cost-effective.

3 system control, zero tool change time.

Super cost-effective CNC precision automatic machine B0128W 9

Back axis side Y axis can realize higher value-added parts processing.

Main Specification

Model		B0128W
Machine capacity	Working bar stock diameter	Ø3~Ø12 mm
	Max. machining length	210mm-stationary guild; 80mm-rotary guide bushing; 170mm-electrical direct driving guild bush; 45mm-Guide bush less
	Max. Main spindle drilling diameter	Ø7mm
	Max. Main spindle tapping diameter	M6
	Back spindle clamping diameter	Ø12mm
	Max. Back spindle drilling diameter	Ø7mm
	Max. Back spindle tapping diameter	M8
	Max. Cross drilling diameter	Ø6mm(option)
	Max. Cross tapping diameter	M5 x 0.8(option)
	Max. Cross slotting cutter diameter	Ø30mm(option)
	Max. Back power head drilling diameter	Ø6mm
	Max. Back power head tapping diameter	M5
Machine	Main spindle speed	200~12,000r/min
	Back spindle speed	200~12,000r/min
	Rotary guide bushing speed	200~ 8,000r/min: Spindle-linked rotary guide bushing; 200~12,000r/min: Direct drive rotary guide bushing
	Tool spindle speed	200 -8,000r/min (option)
	Total tool storage capacity (Standard / Max. : Option)	25
	Tool size	12 mm x 12 mm x 85 mm
	Rapid traverse rate	32 m/min ( X1-X3:12 m/min;Y1-Y3:24m/min;Y2:15m/min)
	Controlled axis ( linear axes )	8-axis
Motor speed conversion	Main spindle	1.5/2.2kw
	Back spindle	1.5/2.2kw
	X1.Z1.Z2.X2.X3 axis Y1.Y2.Y3 axis	0.5kw
	Cross drill(option)	0.75KW (option)
	Back power head	0.75kw
	Cutting fluid pump	0.25kw
	Lubricating oil pump	3 W
Power supply and others	Net weight	2,150 kg
	Power source requirement	14.1 kVA
	Compressed air requirement	0.4 MPa or above
	Air discharge rate	50 NL/min
	Coolant tank capacity	120L
	Length x Width x Height	1,655 x 1,215 x 1,700mm
